Heavy Duty 24" Depth Rack Mountable Sliding Shelf - Solid
Heavy Duty 24" Depth Rack Mountable Sliding Shelf - Solid
Our heavy duty sliding rack shelves are perfect for heavy components peripherals that you want the ability to slide out, either for convenience or to access the back of the equipment.
Made in the USA
Limited Lifetime Warranty
Description
Kendall Howard manufactures and stocks two robust models of solid and vented Heavy Duty Rack Mountable Sliding Shelves, capable of holding up to 200 lbs. each. These sliding rack shelves are ideal for servers or heavy components, providing the flexibility to slide them out and efficiently access equipment.
- 24" shelf depth
- 200 lb. weight capacity
- Mounting depth adjusts from 24" to 36"
- Rounded corners
- 19" EIA compliant
- Easy to install
- Made in the USA
- Limited Lifetime Warranty
Features
Adjustable Mounting Depth
The sliding shelf can be mounted in 4-post racks and cabinets with various depths. The 4-point mounting style can adjust from 24″ to 36″ deep to suit your particular network racking solution.
18.5" Extension
The shelf extends a full 18.5″ out of the rack making it easy to assemble the back of mission control components and maintain your network equipment.
Mounting Options
The mounting ears will mount in any 19″ EIA compliant rack with a minimum mounting depth of 24″ and a maximum mounting depth of 36″. Its built-in lip allows sliding the shelf in and out easily. Due to their innovative design, the 24″ solid sliding rack shelf mounted upside down and be utilized as a drawer.
Warranty
All Kendall Howard rack shelves are made in the USA and are backed by our Limited Lifetime Warranty.
Specifications
| Part Number | 1922-3-600-01 |
| Width | 19" |
| Depth | Adjustable 24" - 36" |
| Height | 2.25" |
| Weight | 21.5 lbs. |
| Shipping Dimensions | 28" L x 21" W x 3" H |
| Material(s) | CRS (Cold Rolled Steel) |
| Color/Finish | Black Powder Coated Finish |
| UPC | 879447006797 |
| Warranty | Limited Lifetime Warranty |
| Shipping Method | FedEx Ground |
What's in the Box
| Item | Quantity |
|---|---|
| Heavy Duty Rack Mountable Sliding Shelf - 24" Depth | 1 |
Resources
| Title | Type | Date | Version | File Size | |
|---|---|---|---|---|---|
Title Heavy Duty Solid Sliding Shelf (1922-3-600-01) Data Sheet |
Type Data Sheet |
Date 12/24 |
Version 1 |
File Size 111.04 KB |
Download |
Title Heavy Duty Sliding Shelf Instructions (Vented and Solid) |
Type Instructions |
Date 08/24 |
Version 1 |
File Size 970.61 KB |
Download |
Title Heavy Duty Rack Mountable Sliding Shelf (Cut Sheet) |
Type Cut Sheet |
Date 12/24 |
Version 1 |
File Size 373.33 KB |
Download |
Title Heavy Duty 24 Depth Rack Mountable Sliding Shelf 1922-3-600-01 STEP |
Type 3D CAD |
Date 09/24 |
Version 1 |
File Size 1.26 MB |
Download |
