12U Compact SOHO Server Cabinet

Item #:1932-3-001-12

12U Compact SOHO Server Cabinet

Item #:1932-3-001-12
The 12U Compact Series SOHO Cabinet is a sleek and robust server cabinet specially designed for the small business, home office, or IT professional who wants better than just “good enough."
Made in the USA
Limited Lifetime Warranty
Certifications
19" EIA compliant
Add to List
Description Features Specifications What's in the Box Resources Accessories Related
Description
The 12U Compact Series SOHO Cabinet is a sleek and robust server cabinet specially designed for the small business, home office, or IT professional who wants better than just “good enough." The small profile cabinet easily rolls under a work surface, tucks away in a closet or squeezes into the places full size racks cannot. Need a desk top solution? Simply remove the casters and it can be set on any flat surface.
  • Locking, lift off front and rear perforated doors
  • Includes casters and one 78 cfm fan and power cord
  • Two sets of adjustable cage nut style rails
  • Rails are adjustable from 3" to 28" deep
  • 400 lb. weight capacity
  • 19" EIA compliant
  • Made in the USA
  • Limited Lifetime Warranty
Features
Quality, Secure Enclosure

The quality construction provides a safe, secure cabinet to store expensive equipment and devices. The locking front and rear doors prevent unauthorized use, especially helpful for network configurations that are in an open office environment.

Lift-Off Front and Rear Doors

Unique hinge system allows the front and rear doors to be easily removed when installing or performing maintenance on equipment such as servers, network switches, battery backups, and more.

Mobility

Included caster kit creates a mobile racking system perfect for home, small office or studio environments.

Adjustable Rails

Universal cage nut style rails can be adjusted from 3″ to 28″ deep to accommodate various depth equipment.

Cooling/Ventilation

Perforated doors, vented side panels, and included 78 cfm fan promote air flow and prevent hot spots.

Cable Routing Slot

The 10″ x 2.25″ cut out on the bottom rear of the cabinet provides a cable entrance point for network, telecom and/or power cables.

Specifications
Part Number 1932-3-001-12
Width 24.44"
Depth 32.25"
Height 27.42"
Weight 92.00 lbs.
Shipping Dimensions 48" L x 32" W x 30" H
Material(s) CRS (Cold Rolled Steel)
Color/Finish Black Powder Coated Finish
UPC 879447000436
Warranty Limited Lifetime Warranty (Fan: 1-Year Warranty)
Shipping Method LTL Freight
What's in the Box
Item Quantity
12U SOHO Server Rack 1
12U SOHO Server Rack Doors 2
Assembly Parts Pack (includes casters, hinges, fan cable, and assembly hardware) 1
Resources
Title Type Date Version File Size
Title
12U Compact SOHO Server Cabinet (1932-3-001-12) Cut Sheet
Type
Cut Sheet
Date
09/23
Version
1
File Size
324.59 KB		 Download
Title
12U Compact SOHO Server Cabinet (1932-3-001-12) Data Sheet
Type
Data Sheet
Date
05/19
Version
1.0
File Size
 Download
Title
1932-3-001-12.STEP
Type
3D CAD
Date
10/20
Version
1
File Size
7.92 MB		 Download
Title
Compact SOHO Server Cabinet Instructions
Type
Instructions
Date
07/21
Version
1
File Size
454.96 KB		 Download
